Electrolux EDC2086PDW User Manual

• There was too much laundry in the
appliance.
• The drum is dirty.
• Incorrect setting of the conductivity
sensor ( See chapter " Settings -
Adjustment of the remaining laundry
moisture degree " for better setting).
• The airflow slots are clogged.
• Room temperature is too low or too
high ( optimal room temperature 19°C
to 24°C )
13. TECHNICAL DATA
Height x Width x Depth 850 x 600 x 580 mm (maximal 640 mm)
Max. depth with the appliance door open 1090 mm
Max. width with the appliance door open 950 mm
Adjustable height 850 mm (+ 15 mm - feet regulation)
Drum volume 118 l
Maximum load volume 8 kg
Voltage 230-240 V
Frequency 50 Hz
Necessary fuse 13 A
Total power 2800 W
Energy efficiency class B
Energy consumption
1)
4,82 kWh
Annual energy consumption
2)
560 kWh
Left—on mode power absorption 0,50 W
Off mode power absorption 0,50 W
Type of use Household
Permitted ambient temperature + 5°C to + 35°C
Level of protection against ingress of sol‐
id particles and moisture ensured by the
protective cover, except where the low
voltage equipment has no protection
against moisture
IPX4
1)
With reference to EN 61121. 8kg of cotton centrifuged at 1000 rpm.
2)
Energy consumption per year in kWh, based on 160 drying cycles of the standard cotton
programme at full and partial load, and the consumption of the low-power modes. Actual en‐
ergy consumption per cycle will depend on how the appliance is used (REGULATION (EU)
No 392/2012).
ENGLISH 17

Electrolux EDC2086PDW Specifications

General

Cord length	1.45 m
Control type	Rotary
Loading type	Front-load
Drum material	Stainless steel
Drying system	Condensation
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Cycle time	105 min
Noise level	65 dB
Drying class	-
Drum capacity	8 kg
Connected load	2800 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy consumption	3.7 kWh
Annual energy consumption	561 kWh

Weight and Dimensions

Width	600 mm
Height	850 mm
Weight	39760 g
Depth with door closed	665 mm
