Programme selector dial and On/Off indicator
light:
the selection of a washing programme occurs by
turning the programme selector dial clockwise or anticlockwise,
until the desired washing programme (see "Washing
programmes" chart) corresponds with the programme selection
marker placed on the dial (position On). The On/Off indicator
light illuminates.
The indicator lights of the phases foreseen for the selected
programme start flashing.
To switch off the machine turn the programme selector dial
until the marker on the dial corresponds with the On/Off
indicator light (position Off). The On/Off indicator light turns off.
With the programme selector dial it is also possible to set the
level of the water softener (see specific paragraph).
"Start/Cancel" button: once a washing programme has
been set, press this button to start the programme.
The start/cancel indicator light (placed above the button)
illuminates.
With this button it is possible to cancel a washing programme
in progress.
Indicator lights: have the following meanings:
As soon as you select a washing programme, the phase
indicator lights for that programme will start flashing.
As the programme starts, the phase indicator lights turn off
except for the indicator light of the phase in progress which will
remain lit with a static light.
The control panel
7
Programme selector
dial
Indicator lights
Door handle
Programme guide
On/Off indicator light
Start/Cancel indicator light
Programme selection marker
Start/Cancel button
Wash: illuminates when the washing and rinsing
phases are running.
Dry: illuminates when the drying phase is running.
End of programme: illuminates when the washing
programme has ended.
It also has added functions of visual
signalling as:
- the setting of the water softener,
- intervention of an alarm due to the malfunction of
the machine.
