5. Connecting ETOG-56T,
ETOR-55 and ETF-744/99
sensors
In this chapter examples of connecting sensors
to ETO2-4550 and ETR2-1550 controllers are
shown.
ETOG-56T and ETOR-55 sensors are factory
terminated with a 10 m-long cable. ETF-744/99
sensors are not equipped with a factory cable,
and the connection must be executed
in-house.
The sensors mentioned above can be extended
with a standard installation cable. Max. lengths
and cross-sections are given in the table below.
Sensor
type
Max. cable
length
[m]
Min. cable
cross-section
m[m ]
2
6 x 1.5
4 x 1.5
2 x 1.5
ETOG-56T
ETOR-55
ETF-744/99
200
200
50
14
Sensors for controllers
ETO2-4550 & ETR2-1550
