Envirovent ECO dMEV LC Instruction Leaflet

ENGLISH
ECO dMEV LC Centrifugal Extractor
Fans
The ECO dMEV LC extractor fan range
is manufactured to the highest standards
of production and quality as laid down by
the international Quality Standard ISO
9001. All components have been
checked and every one of the final
products will have been individually
tested at the end of the manufacturing
process.
On receipt of the product we recommend
that you to check the following:
1- That it is the corr
ec
t model.
2- That the details on the rating label are
those you require: voltage, frequency...
The installation must be carried out in
accordance with the electrical standards
in force in your country.
This appliance is not intended for use by
young children or infirm persons unless
they have been adequately supervised
by a responsible person to ensure that
they can use the appliance safely.
Young children should be supervised to
ensure that they do n
ot
play with the
appliance
Installation
IMPORTANT: Before installing and
wiring the unit, ensure that the main
supply is disconnected.
Fig. 1:
1: Front grille
2: Protection cover
3: Support
4: Connection terminals
5: Cable entry
6: Dip switches
7:
8: Air filter
Potentiometer for speed adjustment
The ECO dMEV LC is suitable for wall or
ceiling mounting and can either extract
directly to the outside or via an individual
ducting system (see Fig. 2).
Make a hole in the wall or ceiling of
diameter 1
05
mm.
If the unit is to be installed with individual
ducting, use a standard duct of diameter
100 mm.
Remove the front grille (1) and the
protection cover (2).
The unit can be mounted on the wall or
ceiling using the 4 plastic plugs and the
screws provided.
Ensure that there are no obstructions to
the airflow and that the impeller turns
freely.
Introduce the mains cable through the
cable entry (5) and fix it to the wall.
Connect the electrical w
iri
ng as set out
below and then mount the protection
cover and the front grille.
Electrical connection
The ECO dMEV LC is an extractor
designed for a single phase supply, with
voltage and frequency as indicated on
the rating plate of the unit. The units are
manufactured with double electrical
insulation (Class II) and therefore they
do not need an earth connection.
The electrical installation must include a
double pole switch with a contact
clearance of at least 3 mm.
The electrical cable must enter the ECO
dMEV LC through the cable entry (5).
Once the cable has b
een in
troduced
proceed using the electrical wiring
diagram applicable to the selected
model.
Operation
The ECO dMEV LC is an extractor fan
designed to operate continuously at low
speed (adjustable) with the facility to be
set to high speed (fixed) through the
following functions depending on the
version: an external switch live or light
switch (S, T and HT versions); the
