Power Handling:
l00 Watt speech and music
Frequency Response:
65 Hz - 20 kHz
Impedance:
4 Ohm nominal
Sensitivity:
87 dB/lW /lm
Amplifier Compatibility:
25 - l00 Watt
Positioning:
20 -50cm (8” - 20”) from a rear wall
Bass Driver:
130 mm polymer cone with 25mm
high temperature voice coil,
injection moulded PP cone
mounted on an inert die-cast
aluminium chassis
Tweeter:
25 mm aluminium dome with high
temperature voice coil and
neodymium shielded magnet
system
Crossover:
Bass driver crossover is achieved
by 3 components in a 2nd order
filter and tweeter uses 4
components in a 3rd order filter at
3kHz crossover
Cabinet:
12 mm HD Chipboard wrap and
25mm MDF front baffle with vinyl
wood finish
Finishes:
Light Cherry, Dark Cherry, or
Black Ash.
Size:
270(H) x 174(W) x 195(D) mm
10.6” x 6.9” x 7.7”, inc grille
Weight:
4.5kg / 10 lb per single speaker
10.5 kg / 21lb boxed gross.
Mini-Monitor
Loudspeakers
SPECIFICATION
