SECTION 2 INTRODUCTION
Input
Primary Input Voltage ....................................................................... 208 Vac, 1-Phase
......................................................................................................... 230 Vac, 1-Phase
Primary Input Current ....................................................................... 30 Amp @ 208 Vac
......................................................................................................... 27 Amp @ 230 Vac
Frequency ........................................................................................ 50/60Hz
Power Factor .................................................................................... 0.81
Nominal Power - MIG ....................................................................... 5.4KVA
Nominal Power - electrode ............................................................... 6.3KVA
Nominal Power - TIG ........................................................................ 3.9KVA
Protective Fuses............................................................................... 20A time-lag
Degree of Protection ........................................................................ IP 21
Insulation Class ................................................................................ F
Operating Temperature .................................................................... From 14°F to 104°F (-10°C to +40°C)
Output
Duty Cycle - MIG .............................................................................. 160A - 60%
Duty Cycle - electrode ...................................................................... 160A - 60%
Duty Cycle - TIG DC......................................................................... 160A - 70%
OCV.................................................................................................. 75V
Arc Voltage - MIG ............................................................................. 13.0 - 23.0
Arc Voltage - electrode ..................................................................... 20.2 - 26.4
Arc Voltage - TIG .............................................................................. 10.2 - 16.4
Regulation range - MIG .................................................................... 20 - 160
Regulation range - electrode ............................................................ 5 - 160A
Regulation range - TIG ..................................................................... 10 - 160A
Hot Start ........................................................................................... Adjustable
Arc Force .......................................................................................... Automatic (built-in)
Antisticking ....................................................................................... Automatic (built-in)
Ignition - electrode ............................................................................ Scratch
Ignition - TIG..................................................................................... Lift-arc
Wire Spool ........................................................................................ 5/15/20kg (12/33/44 lb)
Wire .................................................................................................. Metal, fluxed core (no gas)
Dimensions
Length .............................................................................................. 22.4” (560mm)
Width ................................................................................................ 9.2” (230mm)
Height ............................................................................................... 15.4” (385mm)
Weight .............................................................................................. 33lbs(15Kg )(net)
Ordering Information
MultiMaster
®
160 cvcc Multi-Process Packages
Multimaster packages listed below include power source with built-
in wire feeder with .030/.035 drive roll, primary input cable, welding
gun, work cable with clamp, FREE #10 spool of .030 Coreshield
®
15 wire, and #1 sample 6013LV 1/8” stick electrodes.
Multimaster
®
160 w/13-ft. MXL 200 ........................................... 0558002772
Multimaster
®
160 w/13-ft. MXL 200 & Stinger ........................... 0558002773
Multimaster
®
160 w/13-ft. MXL 200 & Stinger/HW-17/Reg ............0558002774
Table 1 Multimaster 160 Specifications
