4 TECHNICAL DATA
Tig 3001i
Mains voltage 400 V ±10%, 3∼ 50/60 Hz
Mains supply S
sc min
1.4 MVA
Primary current
I
max
TIG
I
max
MMA
13 A
19 A
No--load power demand when in the
energy--saving mode, 6.5 min. after welding
30 W
Setting range
TIG
MMA
4 -- 300 A
16 -- 300 A
Permissible load at TIG
35 % duty cycle
60% duty cycle
100% duty cycle
300 A / 22 V
240 A / 19.6 V
200 A / 18 V
Permissible load at MMA
30 % duty cycle
60% duty cycle
100% duty cycle
300A / 32 V
230 A / 29.2 V
190 A / 27.6 V
Power factor at maximum current
TIG
MMA
0.9
0.89
Efficiency at maximum current
TIG
MMA
81 %
84 %
Open --circuit voltage
MMA
67 V
Operating temperature -- 1 0 t o + 4 0 ˚C
T ransportation temperature -- 2 0 t o + 5 5 ˚C
Constant sound pressure at no--load <70dB(A)
Dimensions lxwxh
with cooling unit
652 X 249 X 423 mm
714 X 249 X 693 mm
Weight
with cooling unit
33.5 kg
54 kg
Insulation class transformer H
Enclosure class IP 23
Application class
Mains supply, S
sc min
Minimum short circuit power on the network in accordance with IEC 61000--3--12
Duty cycle
The duty cycle refers to the time as a percentage of a ten--minute period that you can weld at a cer-
tain load without overloading. The duty cycle is valid for 40˚C.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
