Eubank V SERIES User Manual

8
28 2021-5010 TOP FRONT PANEL V18-24 X X
28 2022-5010 TOP FRONT PANEL V30-36 X X X X X
28 2023-5010 TOP FRONT PANEL V48-60 X X X X X X
29 2021-5011 MIDDLE FRONT PANEL (no fresh air) V18-24 X X
29 2021-5011E MIDDLE FRONT PANEL (economizer f/a) V18-24 X X
29 2021-5011F MIDDLE FRONT PANEL (barometric f/a) V18-24 X X
29 2022-5011 MIDDLE FRONT PANEL (no fresh air) V30-36 X X X X X
29 2022-5011E MIDDLE FRONT PANEL (economizer f/a) V30-36 X X X X X
29 2022-5011F MIDDLE FRONT PANEL (barometric f/a) V30-36 X X X X X
29 2023-5011 MIDDLE FRONT PANEL (no fresh air) V48-60 X X X X X X
29 2023-5011E MIDDLE FRONT PANEL (economizer f/a) V48-60 X X X X X X
29 2023-5011F MIDDLE FRONT PANEL (barometric f/a) V48-60 X X X X X X
30 2021-5014 LOWER CONDENSER PANEL V18-24 X X
30 2022-5014 LOWER CONDENSER PANEL V30-36 X X X X X
30 2023-5014 LOWER CONDENSER PANEL V48-60 X X X X X X
31 2022-5062 DISCONNECT ACCESS DOOR V18-60 X X X X X X X X X X X X X
31A 070518 BREAKER DOOR LATCH V18-60 X X X X X X X X X X X X X
32 659942 AIR FILTER DISPOSABLE 16x25x1 V18-36 X X X X X X X
32 659943 AIR FILTER DISPOSABLE 16x25x2 V18-36 X X X X X X X
32 659926 AIR FILTER DISPOSABLE 20x30x1 V48-60 X X X X X X
32 659924 AIR FILTER DISPOSABLE 20x30x2 V48-60 X X X X X X
654602 ALUMINUM FILTER 5x30x.025 V18-60 X X X X X X X X X X X X X
34 2021-5004 FILTER RACK V18-24 X X
34 2022-5004 FILTER RACK V30-36 X X X X X
34 2023-5004 FILTER RACK V48-60 X X X X X X
35 2022-5021 HEATER MOUNTING PLATE V18-36 X X X X X X X
35 65SM1007-F HEATER MOUNTING PLATE V48-60 X X X X X X
36 EGA05B1-AC FIELD INSTALL HEAT KIT 5KW 1 PHASE 230V X X X X X X
36 0430-0074 HEATER 5KW 1P 240V X X X X X X
36 EGA10B1-AC FIELD INSTALL HEAT KIT 10KW 1 PHASE 230V X X X X X X
36 0430-0072 HEATER 10KW 1P 240V X X X X X X
36 EGH15B1-AC FIELD INSTALL HEAT KIT 15KW 1 PHASE 230V X X X X X X
36 0430-0074 HEATER 5KW 1P 240V X X X
36 0430-0072 HEATER 10KW 1P 240V X X X
36 EGH06B3-AC FIELD INSTALL HEAT KIT 6KW 3 PHASE 230V X X X X
36 458009 HEATER 6KW 3P 240V X X X X
36 EGH11B3-AC FIELD INSTALL HEAT KIT 11KW 3 PHASE 230V X X X X
36 458011 HEATER 11KW 3P 240V X X X X
36 EGH18B3-AC FIELD INSTALL HEAT KIT 18KW 3 PHASE 230V X X X X
36 458013 HEATER 18KW 3P 240V X X
36 EGH06D4-AC FIELD INSTALL HEAT KIT 6KW 3 PHASE 460V X X X
36 458015 HEATER 6KW 3P 460V X X X
36 EGH11D4-AC FIELD INSTALL HEAT KIT 11KW 3 PHASE 460V X X X
36 458017 HEATER 11KW 3P 460V X X X
36 EGH15D4-AC FIELD INSTALL HEAT KIT 15KW 3 PHASE 460V X X X
36 458020 HEATER 15KW 3P 460V X X X
37 2022-HEPL HEATER EXTENSION PLATE H24-36 X X X X X X X
37 2023-HEPL HEATER EXTENSION PLATE H48-60 X X X X X X
38 454332 SWITCH LIMIT 245F ONE SHOT X X X X X X X X X
X X X X
38 454323 SWITCH LIMIT 160-30F 240 W/FUSE X X X X X X X X X X X X X
39 2021-5009H BOX CONTROL V18-24 X X
39 2022-5009H BOX CONTROL V30-36 X X X X X
39 2023-5009H BOX CONTROL V48-60 X X X X X X
40 2021-5017 COMPRESSOR ACCESS DOOR V18-24 X X
40 2022-5017 COMPRESSOR ACCESS DOOR V30-36 X X X X X
40 2023-5017 COMPRESSOR ACCESS DOOR V48-60 X X X X X X
41 2021-5020 BLOWER CUT OFF SHIELD V18-24 X X
41 2022-5020 BLOWER CUT OFF SHIELD V30-36 X X X X X
41 2023-5020-4 BLOWER CUT OFF SHIELD V48 X X X
41 2023-5020-5 BLOWER CUT OFF SHIELD V60 X X X
42 2022-0015 PLATE TOP INSUL PROTECT H/V30-36 X X X X X X X X X X X X X
453150 COMP CONTACTOR 1 POLE 1P 25 AMP X X X X X
453770 COMP CONTACTOR 2 POLE 1P 40 AMP X
453772 COMP CONTACTOR 3 POLE 3P 25 AMP X X X X X X X
452842 PHASE MONITOR X X X X X X X
450362 COMP CAPACITOR 7.5/35@370
0400-0031 COMP CAPACITOR 10/80@370 X
450368 COMP CAPACITOR 7.5/40@370 X
450364 COMP CAPACITOR 7.5/40@440
450361 COMP CAPACITOR 7.5/30@370 X
450370 COMP CAPACITOR 7.5/45@370 X X
450378 COMP CAPACITOR 10/70@370 X
450325 BLWR CAPACITOR 10@370 X X
450205 BLWR CAPACITOR 7.5@370 X X X X X X X
160500730145 BLWR CAPACITOR 7.5@440 X X X X
451000 TERMINAL BLOCK X X X X X X X X X X X X X
452752 TRANSFORMER 208/240V 50VA 24V X X X X X X X X X X
452756 TRANSFORMER 480V 50VA 24V X X X
452200 FAN RELAY X X X X X X X X X X
0821N-0084A FAN RELAY X X X
042004 CIRCUIT BREAKER 2 POLE 1P 60 AMP 240V X X X X X X
453807 CIRCUIT BREAKER 3 POLE 3P 60 AMP X X X X
451955 DISCONNECT KIT 460V X X X
451956 DISCONNECT KNOB 460V X X X
0415-0028 LOW VOLTAGE TERMINAL BOARD X X X X X X X X X X X X X
451049 JUMPER BAR ASSEMBLY
451840 OPTION BOARD
454388 LOW PRESSURE SWITCH
451988 HIGH PRESSURE SWITCH
451992 FAN CYCLE SWITCH
*Part Numbers are Subject to Change
OPTIONAL
OPTIONAL
ELECTRICAL COMPONENTS PARTS LIST
OPTIONAL
OPTIONAL
OPTIONAL
PART NUMBER DESCRIPTION V418B1 V424B1 V430B1 V430B3 V436B1 V436B3 V436B4 V448B1 V448B3 V448B4 V460B1 V460B3 V460B4
2 COMP-L18-001 H62J18BABCA
2 COMP-L24-001 H82J24BABCA
2 COMP-L30-001 H82J28BABCA
2 COMP-L36-001 H82J35BABCA
2 COMP-BZP16-001 ZP16K5EPFV130 X
2 COMP-BZP24-001 ZP24K5EPFV130 X
2 COMP-BZP28-001 ZP28K5EPFV130 X
2 COMP-BZP28-003 ZP28K5ETF5130 X
2 COMP-BZP34-001 ZP34K5EPFV130 X
2 COMP-BZP34-003 ZP34K5ETF5130 X
2 COMP-BZP34-004 ZP34K5ETFD130 X
2 COMP-BZP44-001 ZP44K5EPFV130 X
2 COMP-BZP44-003 ZP44K5ETF5130 X
2 COMP-BZP44-004 ZP44K5ETFD130 X
2 COMP-BZP54-001 ZP57K5EPFV130 X
2 COMP-BZP54-003 ZP57K5ETF5130 X
2 COMP-BZP54-004 ZP57K5ETFD130 X
7 COND-V424 COND COIL X X
7 COND-V436 COND COIL X X X X X
7 COND-V460 COND COIL X X X X X X
8 550510 FLOWRATOR 4 CIRCUIT-COND X
8 550505 FLOWRATOR 3 CIRCUIT-COND X X X X X X
8 550517 FLOWRATOR 6 CIRCUIT-COND X X X X X X
14 EVAP-VH424 EVAP COIL X X
14 EVAP-VH436 EVAP COIL X X X X X
14 EVAP-VH460 EVAP COIL X X X X X X
15 550510 FLOWRATOR 4 CIRCUIT-EVAP X
15 550517 FLOWRATOR 6 CIRCUIT-EVAP X X X X X X
15 550521 FLOWRATOR 9 CIRCUIT-EVAP X X X X X X
550536 RESTRICTOR .063 X X
550531 RESTRICTOR .065 X X
550538 RESTRICTOR .070 X X X
550550 RESTRICTOR .094 X X X
550548 RESTRICTOR .096 X X X
061507 FILTER DRIER X X X X X X X
061508 FILTER DRIER X X X X X X
3 2021-5008 FAN SHROUD V18-24 X X
3 2022-5008 FAN SHROUD V30-36 X X X X X
3 2023-5008 FAN SHROUD V48-60 X X X X X X
4 259108 MOTOR MOUNT CONDENSER FAN X X X X X X X
4 259109 MOTOR MOUNT CONDENSER FAN X X X X X X
5 0250-0025 MOTOR CONDENSER 230V 1/5 HP X X X X X X
5 351145 MOTOR CONDENSER 230V 1/2 HP X X X X
5 359100 MOTOR CONDENSER 460V 1/4 HP X
5 351146 MOTOR CONDENSER 460V 1/2 HP X X
6 0550-0009 FAN BLADE 20" V18-36 X X X X X X X
6 259114 FAN BLADE 22" V48-60 X X X X X X
9 2022-5000 ASSEMBLY LEFT SIDE PANEL V18-36 X X X X X X X
9 2023-5000 ASSEMBLY LEFT SIDE PANEL V48-60 X X X X X X
10 2021-5012 ASSEMBLY REAR PANEL V18-24 X X
10 2022-5012 ASSEMBLY REAR PANEL V30-36 X X X X X
10 2023-5012 ASSEMBLY REAR PANEL V48-60 X X X X X X
11 2021-5003 ASSEMBLY DIVIDER DECK V18-24 X X
11 2022-5003 ASSEMBLY DIVIDER DECK V30-36 X X X X X
11 2023-5003 ASSEMBLY DIVIDER DECK V48-60 X X X X X X
12 2021-5005 ASSEMBLY BLOWER PAN V18-24 X X
12 2022-5005 ASSEMBLY BLOWER PAN V30-36 X X X X X
12 2023-5005 ASSEMBLY BLOWER PAN V48-60 X X X X X X
13 2021-0006P ASSEMBLY DRAIN PAN V18-24 X X
13 2022-0006P ASSEMBLY DRAIN PAN V30-36 X X X X X
13 2023-5006 ASSEMBLY DRAIN PAN V48-60 X X X X X X
17
2021-5002 BASE PAN ASSEMBLY V18-24 X X
17 2022-5002 BASE PAN ASSEMBLY V30-36 X X X X X
17 2023-5002H BASE PAN ASSEMBLY V48-40 X X X X X X
22 2021-5018 BLOWER MNTG TRAY V18-24 X X
22 2022-5018 BLOWER MNTG TRAY V30-36 X X X X X
22 2023-5018-4 BLOWER MNTG TRAY V48 X X X
22 2023-5018-5 BLOWER MNTG TRAY V60 X X X
23 2022-5001 ASSEMBLY RIGHT SIDE V18-36 X X X X X X X
23 2023-5001 ASSEMBLY RIGHT SIDE V48-60 X X X X X X
23A 2023-5088 GRILL INLET RIGHT SIDE V48-60 X X X X X X
23B 2023-5089 GRILL INLET LEFT SIDE V48-60 X X X X X X
24 194700050002 BLOWER 9-7R DD 18, 24, & 48 CW RIGHT X X X X X
24 194700050004 BLOWER 10-7R DD 60 CW RIGHT X X X
24 0500-0010 BLOWER 10-10 DD 30 & 36 X X X X X
24A 1947000050001 BLOWER 9-7L DD 48 CCW LEFT X X X
24A 194700050003 BLOWER 10-7L DD 60 CCW LEFT X X X
25 351115 MOTOR BLOWER 1/6 HP 230V X X
25 194090000006 MOTOR BLOWER 1/3 HP 230V X X X X
25 020008 MOTOR BLOWER 1/2 HP double shaft 230V X X
25 351424 MOTOR BLOWER 3/4 HP double shaft 230V X X
25 359101 MOTOR BLOWER 1/3 HP 460V (2-3 ton) X
25 020005 MOTOR BLOWER 1/2 HP double shaft 460V X
25 351426 MOTOR BLOWER 3/4 HP double shaft 460V X
26 BLWR-MTG2B MOTOR MOUNT INDOOR ASSY V18-24 X X
26 258972 MOTOR MOUNT INDOOR ASSY V30-36 X X X X X
26 258976 MOTOR MOUNT INDOOR ASSY V48-60 X X X X X X
27 2021-5007 TOP V18-24 X X
27 2022-5007 TOP V30-36 X X X X X
27 2023-5007 TOP V48-60 X X X X X X
REPLACEMENT PARTS LIST - V SERIES WALLMOUNT A/C
