EvaKool DOWN UNDER Series User Manual

5
3. Operation
• Power: The refrigerator can be powered by a multi-voltage system utilising either 12/24
Volts or with the included 240V adaptor. The electronic module controls the compressor
and has the added function of a three stage battery protection. When the input voltage
drops below the minimum, the compressor will cut out; when the voltage comes back
up to the cut-in value, the compressor will restart automatically.
• Battery Protection: The SECOP compressor requires approximately 11.0 Volts (12 Volt
System) or 23.0 Volts (24V System) to operate. If the voltage drops below this the fridge
will stop running.
• Cable Specification: The DC cables must have a suitable cross-section for their length
(measured from the battery to the unit), according to this table:
Cable Thickness (Area) 12V Max Cable Length 24V Max Cable Length
(mm
2
) AWG (m) () (m) ()
2.5 13 2.5 8 5 16
4 11 4 13 8 26
6 9 6 20 12 39
10 7 10 33 20 66
DOWN UNDER SERIES
RECOMMENDED TEMPERATURE SETTINGS
Fridge 2°C
Freezer -16°C
COMPRESSOR SPEED SETTINGS
Eco Recommended for ambient temperatures of 30°C or less.
Max Recommended for ambient temperatures of 30°C or more.
For Maximum Eiciency
• Use the included baskets to ensure air circulation freely around the cabinet.
• Ensure the vents are not obstructed as to allow maximum airflow.
• Refrain from unnecessary opening of the unit.
