Exmark LAZER Z E Series User Manual

Operation
Toadjustthefront,shockassembly,opentheoor
panandadjustitbyusingaspannerwrench(Part
No.132–5069)oraslip-jointpliers(Figure25).
1
g029989
2
3
Figure25
1.Middleposition3.Firmride
2.Softride
Transporting
TransportingtheMachine
Useaheavy-dutytrailerortrucktotransportthe
machine.Ensurethatthetrailerortruckhasall
necessarylightingandmarkingasrequiredbylaw.
Thoroughlyreadallofthesafetyinstructions.
Knowingthisinformationcouldhelpyou,your
family,pets,orbystandersavoidinjury.
Totransportthemachine:
•Lockthebrakeandblockthewheels.
•Besurethefuelshut-offvalveisclosed.
•Securelyfastenthemachinetothetrailerortruck
withstraps,chains,cable,orropes.
•Secureatrailertothetowingvehiclewithsafety
chains.
WARNING
Drivingonthestreetorroadwaywithoutturn
signals,lights,reectivemarkings,oraslow
movingvehicleemblemisdangerousandcan
leadtoaccidentscausingpersonalinjury.
Donotdrivemachineonapublicstreetor
roadway.
LoadingtheMachine
Useextremecautionwhenloadingorunloading
machinesontoatraileroratruck.Useafull-width
rampthatiswiderthanthemachineforthis
procedure.Backuprampsanddriveforwarddown
ramps(Figure26).
g028043
Figure26
1.Backupramps
2.Driveforwarddown
ramps
Important:Donotusenarrowindividualramps
foreachsideofthemachine.
Ensuretherampislongenoughsothattheanglewith
thegrounddoesnotexceed15degrees(Figure27).
Onatground,thisrequiresaramptobeatleastfour
times(4X)aslongastheheightofthetrailerortruck
bedtotheground.Asteeperanglemaycausemower
componentstogetcaughtastheunitmovesfromthe
ramptothetrailerortruck.Steeperanglesmayalso
causethemachinetotiporlosecontrol.Ifloadingon
ornearaslope,positionthetrailerortrucksothatit
isonthedownsideoftheslopeandtherampextends
uptheslope.Thiswillminimizetherampangle.
38
