13 TM500-EU-EN v1.1 12/13

Specifications

GeneralSpecifications

Display BacklitLCD;LCDsize:

82×61mm(3.23×2.40")

Statusindicators Over‐range(‐‐‐‐)andlow batt ery  

MeasurementChannels T1toT12

Sensortypes Thermocoupletypes:K,J,T,E,R,andS

MeasurementUnit s °C/°F

Offset Adjustment Toadjustthezerotemperature devia tio n value

LinearityCompensation Linearcompensat io nforthefullra nge

Datalo gger SamplingRate AUTOLOGGING:1,2,5,10,30,60,120,300,60

0,1800,

3600seconds.Notethataone(1)seco ndsamplingra te 

cancau sesomedatalos sonslowercomputers

MemoryCard SDmemory card;1Gto16GBsize

TemperatureCompe nsat ion Automaticcompensationforallth ermoco uple types

Displayupda te rate Approx.1sec ond.

DataOutput RS‐232/USBPCcomputerin

terface(9600,N,8,1)

eratingTemperat ure 0to50°C(32to122°F)

OperatingHumidi ty  85%R.H.max imum

AutoPowerOFF

After10 minutesofinactivity(canbedisa bled)

PowerSupply Eight(8)1. 5 VDCbatter ies (optional9VACadaptor)

PowerConsumpt io n Withbacklight&data logger OFF:approx.7.5mAdc

Withbackli

ghtOFFandda ta logger ON:approx.25mAdc

WithbacklightONanddataloggerON:approx.36mAdc

Weight 827g(1.84lbs.)meteronly

Dimensions Maininstrument:225x125x64mm(8.86x4.92x2.52”)
