STAGE® 100/160 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
7
PARTS LIST:
MAIN – PCB ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
2 0041074000 ENCODER 16-POS 4-BIT BINARY S4-5
REV SELECT, FX SELECT
16 0025802000 FASTON TAB, .250" P1-16
2 0020775000
**FUSE CLIP PCB 5mm
@ F1
1 0027416000 HDR .1 CTR 8 CKT SQ PIN P20
1 0057350000 HDR .1 CTR 8x2 CKT SQ PIN P19
1 0025796000 HEATSINK TO-220 @ U11
1 0054259000 HEATSINK PLATE STAGE 100/160
6 0032908000 SCRW TF 6-32x3/8 PHP ZI @ HEATSINK
1 0016795000 IC OP-AMP DUAL TL072 U1
1 0028120000 IC 4053B TPL 2 CHAN ANLG SW U10
8 0031611000 IC OP-AMP DUAL PC4560 U2-9
2 0041261000 IC VOLT REF LM4040DIZ-10.0 D68-69
1 0041812000 IC REGULATOR +5V MC7805CT U11
1 0027387000 INDUCTOR AIR CORE RDL 2.5uH L1
3 0051658000 JACK MONO R/A J2-3 J6
FTSW, PRE AMP OUT, MAIN SPKR
3 0053450000 JACK STEREO R/A J1 J4 J7
INPUT, PWR AMP IN, EXT. SPKR
1 0054261000 JACK XLR MALE RT ANGLE J5
LINE OUT
1 0040271000 LED RED/YELLOW D78
DRIVE STATUS
2 0049948000 LED, RED LONG LEAD LUMEX D9-10
DISTORTION
1 0055812000 LED TULIP ASSY D45
POWER
4 0024947001 RES CF 1/4W 5% 47ohm LL R7 R196-197 R203
1 0024954001 RES CF 1/4W 5% 150ohm LL R81
4 0024956001 RES CF 1/4W 5% 220ohm LL R87 R94 R198-199
1 0029604001 RES CF 1/4W 5% 300ohm LL R80
1 0024961001 RES CF 1/4W 5% 470ohm LL R36
10 0024965001 RES CF 1/4W 5% 1k LL
R20 R85 R95-96 R118-119 R127 R131 R151 R202
10 0024969001 RES CF 1/4W 5% 1.5k LL
R24 R98-99 R102-103 R106-107 R132 R162 R181
10 0024971001 RES CF 1/4W 5% 2.2k LL R17 R49-50 R66-67 R82 R84 R89 R92 R117
2 0024972001 RES CF 1/4W 5% 2.7k LL R90-91
5 0024973001 RES CF 1/4W 5% 3.3k LL R28 R76 R88 R93 R133
2 0024977001 RES CF 1/4W 5% 4.7k LL R47 R77
6 0028034001 RES CF 1/4W 5% 5.1k LL R4 R25 R68-71
2 0024979001 RES CF 1/4W 5% 6.8k LL R5 R14
1 0024980001 RES CF 1/4W 5% 8.2k LL R23
19 0024981001 RES CF 1/4W 5% 10k LL R26 R33 R51-53 R62-63 R97 R115-116 R129
R136-137 R139 R143-144 R183 R185 R193
2 0024985001 RES CF 1/4W 5% 15k LL R1 R6
7 0024987001 RES CF 1/4W 5% 22k LL R8 R12 R21-22 R48 R150 R153
10 0024988001 RES CF 1/4W 5% 27k LL R59-60 R64-65 R72-75 R113-114
5 0024989001 RES CF 1/4W 5% 33k LL R29 R40 R43 R46 R176
6 0024993001 RES CF 1/4W 5% 47k LL R32 R37 R39 R78-79 R195
1 0024995001 RES CF 1/4W 5% 68k LL R44
21 0024997001 RES CF 1/4W 5% 100k LL R18-19 R35 R41 R54 R61 R83 R86 R128 R130
R145-148 R165 R172 R182 R188-190 R200
2 0025058001 RES CF 1/4W 5% 180k LL R13 R55
3 0025059001 RES CF 1/4W 5% 220k LL R15 R31 R180
2 0025061001 RES CF 1/4W 5% 330k LL R175 R184
5 0025065001 RES CF 1/4W 5% 470k LL R30 R159 R169 R171 R174
2 0028018001 RES CF 1/4W 5% 510k LL R2-3
1 0025068001 RES CF 1/4W 5% 820k LL R168
10 0025069001 RES CF 1/4W 5% 1M LL R149 R152 R166 R170 R173 R177 R186-187
R194 R201
1 0031767001 RES CF 1/2W 5% 15ohm LL R126
1 0047750001 RES CF 1/2W 5% 330ohm LL R154
To Next Page
