5. Exterior structure
30
All of the fastenings on the service ap must lock into
place when closing to ensure that the ap will always
be closed tight. If the ap is not closed correctly, it
could become permanently deformed, especially when
the caravan stands unused for a longer period of time.
Spray the sealing gaskets of the service aps regularly
with silicon to ensure that they will always move easily
and operate reliably.
To open
• Unlock the ap
j
with a key.
• Press locking knob
k
while pushing lighting on the ap.
• Open the ap by pushing down.
To close
• Close the ap by pushing it up.
• Press the top left and right-hand corners of the ap to ensure
that all of the existing locks actually snap into place.
• Use the key to lock the ap
j
.
5.3 Service ap
(model-specic / special accessory)
2
1
Storage locker ap
(model-specic)
To open
• Unlatch both locks with the key.
• At the same time, pull both locking handles outwards around
the ap to open it.
To close
• Close the ap.
• Press on the ap by the locks so that the locks actually click
into place.
• Latch both locks with the key.
The storage locker ap is only guaranteed to be perma-
nently tight if all of the locks click into place when the
ap is closed. If the ap is not closed correctly, it could
become permanently deformed, especially when the
caravan stands unused for a longer period of time.
Spray the seals of the storage locker ap regularly
with silicone to ensure that the service ap always
moves freely and operates reliably.
