FENDT Diamant Series User Manual

08-3
Fresh water tank, 25 or 45 l
(model-specic, special accessory)
The tank
j
holds either approx. 25 or 45 litres.
However, due to its design the actual amount of
water may vary slightly.
The tank is lled with fresh water by means of
the ller neck
k
on the side wall.
The fresh water ller neck is identied by a blue
screw cap as well as a water faucet symbol on
the lower edge of the frame. The screw cap is
opened and closed by means of the enclosed
key for exterior ap locks and the door of the
structure.
Should the tank overow, the excess water is
drained off underneath the vehicle by means of
an overow (45 l tank only).
The water can be emptied from the tank by un-
screwing the overow pipe
l
(45 l tank only).
For a 25 l tank:
• Remove the drain plug
m
.
• Loosen the grommet by turning it counter-
clockwise 2-3 times, then release the tension
by pressing it in. Then remove the stopper by
pulling it up.
8.2 Warm water supply via Truma-Therme
1
3
2
4
Rules for warm water supply:
•
Only use water suitable for drinking.
Note the user's guide before rst
use!
To ll the therme:
•
Open the warm water faucet or set the one-
level mixer to "warm".
• Leave the faucets open until the Truma-
Therme is lled by blocking the air and hot
water ows.
