FENDT Vario 718 User Manual

CHAPTER
3
Manual No. 016-5030-043 Rev. A 9
C hapter 3 Mechanical Drive
Installation
FIGURE 1. Spline Assembly Disassembled
1. Locate the 20 mm x 36 tooth spline adapter assembly (P/N 063-4001-022).
2. Disassemble the spine adapter assembly as shown in Figure 1 above.
Remove the Steering Wheel
Note: The steps in this section require use of a steering wheel puller (not supplied). For questions on the
proper procedure for removing the steering wheel, contact your local equipment dealer.
Nut
Washer
Female Spline
Adapter
Bolts
Male Spline
Adapter

FENDT Vario 718 Specifications

General

Max Speed	50 km/h
Fuel Tank Capacity	330 l
Transmission	Continuously variable transmission (CVT)
Hydraulic System	Load sensing system
Engine Type	Diesel
Tire Options	Various options available
