9 – MOTOR PROGRAMMING
Once the Motor Kit is installed and verifi ed that the operating voltage is 12 V (not higher), the Motor Kit
Advanced can be operated either with the button (supplied with the Motor Kit) or with the App.
The Motor Kit is equipped with an automatic system that allows the fabric to tension itself once it has
been opened completely.
Self-tensioning: when the fabric is completely unrolled, it retracts for a preset time, so that it tensions
up. The Motor Kit can be installed on awnings with different fabric extension (related to the length of the
awning), thus the automatic system must be “set” beforehand.
CONTROL UNIT PROGRAMMING (SETTING)
Through this procedure the system recognises the complete extension of the awning fabric and
automatically defi nes the self-tensioning, visible the next time it is opened. The self-tensioning of the
fabric only works when the awning is opened.
For this operation, perform the following steps:
• Disconnect the 12 V power supply to the control unit
• Press and hold the EXTEND button
• Restore the 12 V power supply; after about 10 seconds the awning will start to open
• When the awning is fully open, or has reached the maximum extension of the fabric, release the
EXTEND button
• Wait at least 10 seconds or, if installed, for the LEDs to turn off, then press and hold down the
RETRACT button until the awning is completely closed
• The awning is ready for use
The awning can be operated either with the button or with the App
USE WITH BUTTON (AUTOMATIC MODE)
Opening:
• Press the EXTEND button for less than 2 seconds
• The awning will open at the maximum extension of the fabric, making the self-tensioning (in
automatic mode, when opening, it is always active)
Closing:
• Press the RETRACT button for less than 2 seconds
• The awning will close completely
Note: the duration of automatic opening is timed and does not take into account the position of the
lead bar; if the lead bar is already open, opening in automatic mode will take place for the preset time.
USE WITH BUTTON (MANUAL MODE)
Opening:
• Press the EXTEND button for more than 2 seconds
• The awning will open until the button is released (by releasing it, the engine stops). In this mode the
self-tensioning is not active
Closing:
• Press the RETRACT button for more than 2 seconds
• The awning will close until the button is released (by releasing it, the engine stops).
Note: opening the awning in manual mode up to a certain extension, stopping it and then restarting in
automatic mode, the opening in automatic mode will take place for the preset time.
Use with App
• Download the Fiamma App on your device (see picture)
• Activate Bluetooth® on your device
• Connect the App to the awning with the Connect button. If the Fiamma network is not displayed,
click on Update Networks
• Download and read the App’s instructions carefully before use: the App includes the buttons for
opening and closing the awning, as well as for switching on and off any lights installed on the awning
The App communicates with the Motor Kit control unit via Bluetooth®, which is generated by the
control unit; if there is no 12 V voltage, the App does not work.
Note: opening the awning up to a certain extension, stopping it and then restarting, the opening in
automatic mode will take place for the preset time
