User Manual for Firefly Microscope DE500 Version: 1.0
Using the Firefly Microscope System:
Recommended holding position:
It is suggested to hold the microscope, transparent cover forward, with the thumb held on
the equipment. This holding position offers relative stability and allows lens control. The index finger is
still free to rotate and adjust the focus wheel (as shown).
Brightness Adjustment:
On left rear side of the microscope, a knob allows the user to control the
brightness of the LEDs:
Backward Turn: Decrease Brightness
Forward Turn: Increase Brightness
Using the image capture control:
Press and release
the Capture
button
to capture image frames. The system
will generate a shutter sound from the PC speaker as confirmation.
C a p t u r e
