Operation Manual of Diesel Generator
3. Specifications
3-1 Main technical specifications
Model
Item
SDG2500CL
SDG2500CLE
SDG2500CX
SDG2500CXE
SDG4000CL
SDG4000CLE
SDG2500CX
SDG2500CXE
SDG5500CL
SDG5500CLE
SDG5500CX
SDG5500CXE
SDG3500SE SDG5000SE
Type 2 electrode single-phase alternating current generator
Excitation system Self-excitation system
Voltage adjusting system Condenser compensating system
Frequency (Hz) 50 60 50 60 50 60 50 60 50 60
Rated output (KVA) 1.8 2.0 2.8 3.0 4.5 5.0 2.8 3.0 4.2 4.5
Max. output (KVA) 2.0 2.2 3.0 3.3 4.8 5.3 3.0 3.3 4.5 4.8
Rated Voltage (V) 110,115,120,220,230,240,110/220,115/230,120,240
Power factor (cos Φ) 1
generator
DC output (V-A) 12 – 8.3
Model SDE170 SDE178 SDE186 SDE178 SDE186
Type Air-cooled 4-cycle Diesel Engine
Displacement (cc) 219 306 418 306 418
Continuous rated output
(kw/rpm)
2.5/
3000
2.8/
3600
3.7/
3000
4.0/
3600
5.7/
3000
6.3/
3600
3.7/
3000
4.0/
3600
5.7/
3000
6.3/
3600
Fuel Diesel light oil
Fuel tank capacity (L) 10 13
Continuous running time
(at the rated output)
11 9.6 7.7 7.0 5.1 4.5 10.0 9.1 6.6 5.9
Lube oil capacity (L) 0.80 1.10 1.65 1.10 1.65
engine
Starting system Recoil start/electric start Electric start
Protective system
of low oil pressure
CX,CXE type have have
Dimensions ( L X W X H )
625X455X520 690X455X545 700X465X600 840X530X740 910X530X740
set
Net weight (KG) 54/58(E) 64/68(E) 98/102(E) 127 154
3-2 Basic parameters
3-2.1 Under the following conditions, the generator set should output the rated power:
Altitude height (m)
Ambient temperature (℃)
Relative humidity (%)
0 20 60
3-2.2 Under the following conditions, the generator set should output the stipulated power and
work reliably:
Altitude height (m)
Ambient temperature (℃)
Relative humidity (%)
<1000 5~40 90
5
