18
HOME RECHARGER
Recharging Nicad batteries with the optional 110-volt
recharger is a simple procedure:
1. Remove and disconnect the Nicad battery
pack from the IMPULSE Control Housing.
2. Connect the recharger battery lead to the
battery pack.
3. Plug the recharger into a wall outlet, and the
batteries will begin recharging immediately.
4. The small, green light in the charger will stay on
during the entire charge cycle, indicating that all
connections have been made and the charger
is working.
5. A full charge will take about 24 hours. Do not
charge more than 48 hours.
“captive screws” and do not have to be
completely removed from the battery cover.)
2. Remove the battery pack from the Control
Housing and disconnect the battery lead
connector. Be very careful not to put any undue
strain on the battery leads.
3. Remove the batteries from the battery packs.
Note the polarity markings inside the pack and
install fresh batteries. You may use regular carbon
zinc, alkaline or rechargeable Nicads.
4. Reconnect the battery lead.
5. Insert the battery pack into the Control
Housing with the lead connector on top. Fold the
leads across the top of the pack.
6. Make sure the O-Ring and both sealing
surfaces are clear before reinstalling the battery
cover. THIS IS EXTREMELY IMPORTANT!
7. Finger tighten the thumbscrews, and then
carefully tighten again 1/4 turn with a coin or
screwdriver.
BATTERIES
