Prepare the Instrument
TELECASTER
TM
STYLE GUITARS
File or sand down the corners of
the 9-Pin Jack to fit the standard
Telecaster
TM
mounting hole.
STRATOCASTER
TM
STYLE GUITARS
You will need to drill out the back wall of the jack cavity to accommodate the
supplied 9-Pin Jack. Remove the output jack from the jack plate, then
replace the jack plate on the guitar. Use a pencil through the jackplate to
mark the center where your drill will enter the back of the jack cavity. Use a
3/4” (19mm) spade bit to drill out the back of the jack cavity.
Powerchip
6
