Flymo MINI TRIM User Manual

MANUAL LINE FEED SYSTEM
H1 - Line Cutter
J1 - Cleat
J2 - Latches
J3 - Spool
J4 - Spoolholder
J5 - Slot
L1 - Line Lock Hole
T
o feed the nylon line
1. Press and hold the two latches (H).
2. Gently pull the line until it reaches the line cutter.
3. Release the two latches. Check that the spool is
locked in position.
4. If too much line has been fed out, press the two
latches and turn the spool anti-clockwise until
the line is at the desired length.
T
o remove spool
1. Press and hold the two latches.
2. Pull spool out of spoolholder (J).
When r
efitting the spool
1. Keep all areas of the spool and spoolholder
clean. Failure to do so may prevent the spool
from being securely located in the spoolholder.
2. Make sure the line is placed through the slot in
the spoolholder (K).
3. Place spool into spoolholder and press down
into place.
4. Check that the spool is corr
ectly fitted by
trying to remove the spool without
depressing the latches (K1).
To replace nylon line
Replacement line is available from most Electrolux
Outdoor Products stockists. You can buy it either
as spool and line complete or as nylon line only.
T
o replace spool and line complete
1. Remove old spool.
2. Release line from cleat. Unwind approximately
100mm of line and feed through slot in
spoolholder (K).
3. Re-fit spool into spoolholder. Check that the
spool is locked in position.
T
o replace nylon line on spool
1. Take approximately 5 metres of line line and
insert into one of the line lock holes in the spool
(L).
2. Wind line onto spool in the direction of the
arrows on the top of the spool. Care should be
taken to ensure that the line is neatly coiled on
the spool (L).
3. Leave approximately 100mm of line unwound
and feed through slot in spoolholder (K).
4. Replace spool into spoolholder.
Ensure spool is correctly fitted.
Remember! Your Flymo trimmer is designed to
use only nylon line with a maximum diameter of
1.5mm. Use only genuine Flymo nylon line.
Fault Finding Hints
WARNING! Disconnect from the mains
electricity supply before attempting any
maintenance or adjustment.
1. Line too short.
Feed out line.
2. Line broken inside of spoolholder.
Remove spool and re-thread line.
3. Line jammed on spool.
Remove spool and rewind line to remove
crossed loops.
4. Poor performance.
Ensure the inside of the spoolholder is clean and
free from debris.
5. Line snaps continuously.
Use only tip of nylon line to trim. If symptoms
still persist, change spool and line.
6. Line will not pull out.
Check that line has been released from cleat.
7. IF FAULT PERSISTS
Contact your local approved Electrolux Outdoor
Products Service centre.
AUTOMATIC LINE FEED SYSTEM
M1 - Line cutter
N1 - Manual line feed button
P1 - Cap
P2 - Cap release latch
P3 - Spool
P4 - Spoolholder
P5 - Eyelet
Q1 - Cut out area of spool
Q2 - Eyelet
R1 - Cleat
How the automatic line feed works (M)
1. When initially switching on the trimmer, a small
length of line is fed out.
2. A ‘clattering’ noise will be heard when the nylon
line hits the line cutter. DO NOT BE ALARMED
this is quite normal. After approximately 5
seconds the line will be cut to the correct length
and the noise will reduce as the motor reaches
full speed.
• Make sure the motor is up to full speed
before trimming.
3. If the noise of the nylon line being cut cannot be
heard, more line will need to be fed out.
4. To feed more line, it is first necessary to to allow
the motor to stop completely, then re-start,
allowing the motor to reach full speed.
5. Repeat step 4. until you hear the line hitting
against the cutter. (Do not repeat this procedure
more than 6 times)
6. If problems are experienced with the automatic
line feed refer to Fault Finding Chart.
T
o manually feed the nylon line (N)
1. If required line can be fed out manually.
2. To operate, press and release manual line feed
button, whilst gently pulling on one of the lines
until the line reaches the line cutter.
3. When the required amount of line is fed out,
gently pull on the second line (there is no need
to press the manual line feed button again).
4. If the line extends past the line cutter, too much
line has been fed out.
5. If too much line is fed out, remove the spool cap
and click spool anti-clockwise until the line is at
the desired length.
ENGLISH - 3
