SM9 - ProfeSSional analog Monitoring SySteM
User Manual
9
PERFORMANCE
Frequency response
3-way mode 30Hz - 40kHz (+/- 3dB)
40Hz - 20kHz (+/- 1dB)
2-way mode (Focus) 90Hz - 20kHz (+/- 3dB)
Maximum SPL
3-way mode 116dB SPL (peak @ 1m)
2-way mode (Focus) 106dB SPL (peak @ 1m)
ELECTRONIC SECTION
Input
Type / Impedance
Connector
Sensitivity
Electronically balanced / 10 kOhms
XLR
Adjustable, +4dBu or -10dBV
Bass
Midrange
Treble
400W, class AB
100W, class AB
100W, class AB
Power supply
Local supply
Connection
230V (3.15A fuse)
115V (6.3A)
IEC inlet and detachable power cord
User controls and indicators
Rear panel
Side panel
Input sensitivity selector (+4dBu / -10dBV)
High-pass crossover (full range, 45, 60, 90Hz @ -6dB)
Low frequency shelving
(+/- 3dB from 30 to 250Hz per step of 0.5dB)
High frequency shelving
(+/- 3dB from 4.5 to 40kHz per step of 0.5dB)
Low frequency EQ
(+/- 3dB per step of 0.5dB @ 50Hz, Q factor = 2)
Low-mid frequency EQ
(+/- 3dB per step of 0.5dB @ 160Hz, Q factor = 1)
Mid frequency EQ
(+/- 3dB per step of 0.5dB @ 1kHz, Q factor = 0.6)
Stand By / On switch
Direct switch
Focus switch
Light indicator
Power On, clipping and default on front panel LED
TRANSDUCERS
Passive radiator
11WPP52, 11” (27cm) Focal “W” composite sandwich cone piston, extra wide inverted surround
radiator
Subwoofer
8W7571, 8” (20cm) Focal “W” composite sandwich cone driver
Midrange
6W0452, 6.5” (16.5cm) Focal “W” composite sandwich cone driver
Tweeter
TB872, 1” pure Beryllium inverted dome tweeter
CABINET
Construction
0.88”(22mm) and 1.2” (30mm) panels with internal braces
Finish
Black natural veneering top and bottom panels, black body
Dimensions (HxLxD)
12.8” x 19.6” x 15.6” (320mm x 490mm x 390mm)
Weight
77lb (35kg)
