Fuse/Relay
Location
Fuse Amp
Rating
Description
116 40A** Rear Window Defroster, Heated Mirrors
117 — Not Used
118 — Not Used
201 — Trailer Tow Park Lamp Relay
202 — Front Wiper Run/Park Relay
203 — Trailer Tow Backup Lamp Relay
204 — A/C Clutch Relay
205 — Horn Relay
206 — Foglamp Relay
207 — Front Washer Pump Relay
208 — Rear Washer Pump Relay
209 — Front Wiper Hi/Lo Relay
210 — Not Used
211 — Not Used
212 — Rear Wiper Up Relay
213 — Rear Wiper Down Relay
301 — Fuel Pump Relay
302 — Trailer Tow Battery Charge Relay
303 — Not Used
304 — Powertrain Control Module Relay
401 — Not Used
501 — Powertrain Control Module Diode
502 — A/C Clutch Diode
503 — Not Used
601 30A Delayed Accessory (Power Windows, Flip
Windows, Moonroof)
602 — Not Used
*Mini fuses **Maxi fuses
Relays
Relays are located in the power distribution box and should be replaced
by qualified technicians.
Roadside emergencies
136
