Trip odometer
Registers the kilometers (miles) of
individual journeys. To reset,
depress the control.
Refer to Electronic Message Center for Trip A and Trip B features on
the optional instrument cluster.
Engine coolant temperature gauge
Indicates the temperature of the engine coolant. At normal operating
temperature, the needle remains within the normal area (the area
between the “H” and “C”). If it enters the red section, the engine is
overheating. Stop the vehicle as soon as safely possible, switch off the
ignition and let it cool. Refer to Engine coolant in the Maintenance
and care chapter.
Never remove the coolant recovery cap while the engine is
running or hot.
• Standard instrument cluster
0000
20
30
40
50
60 70
80
90
100
110
120
10
20
40
60
80
100
120
140
160
180
MPH
km/h
0 00000
TEMP
H
C
Instrumentation
18
