Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
5 — Not Used
6 10A* Powertrain Control Module
7 30A* 4 Wheel Anti-Lock System
(4WABS) Module
8 15A* Rear Wiper Motor
9 20A* Fuel Pump Relay and RAP
Module
10 15A* Horn Relay
11 15A* Parklamps Relay and Mainlight
Switch
12 30A* Mainlight Switch and
Multifunction Switch
13 15A* Heated Oxygen Sensor, EGR
Vacuum Regulator, EVR Solenoid,
Camshaft Position (CMP) Sensor,
Canister Vent Solenoid
14 30A* Generator/Voltage Regulator
15 — Not Used
1 — Wiper Park Relay
2 — A/C Relay
3 — Wiper High/Low Relay
4 — PCM Power Relay
5 — Fuel Pump Relay
6 — Starter Relay
7 — Horn Relay
8 — Rear Wipe Down Relay
9 — Blower Motor Relay
10 — Rear Wipe Up Relay
1 — Not Used
1 — DRL Diode
2 — Electronic Engine Controls Diode
* Mini Fuses ** Maxi Fuses
Roadside emergencies
198
