Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse Panel
Description
27 25A LCM for cornering lamps and high beam
headlamps
28 20A* Power windows, DDM
29 — Not used
30 — Not used
31 — Not used
32 — Not used
* Circuit breaker
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
Always disconnect the battery before servicing high current
fuses.
Always replace the cover to the power distribution box before
reconnecting the battery or refilling fluid reservoirs
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and specifications chapter.
2003 Crown Victoria (cro)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
168
