Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
111 30A** 4WD/Shift on the fly
112 30A** Left-hand power seats
113 30A** Starter motor
114 30A** Right-hand power seats
115 20A** Trailer tow battery charge
116 30A** Ignition switch
601 30A CB Window motors, Moonroof
602 60A** 4WABS module
210 — Not used
211 — Backup lamps relay (Diesel engine
only)
212 — Not used
301 — Front blower motor relay
302 — Powertrain Control Module (PCM)
relay
303 — Fuel heater relay (Diesel engine
only)
304 — Heated backlight relay
305 — Trailer tow battery charge relay
306 — Delayed accessory relay
307 — Starter relay
* Mini Fuses ** Maxi Fuses ***Circuit Breaker
Note: (Diesel engine only) The Fuel Injection Control Module (FICM)
logic 10A mini-fuse is located in the underhood relay block.
CHANGING THE TIRES
If you get a flat tire while driving, do not apply the brake heavily.
Instead, gradually decrease your speed. Hold the steering wheel firmly
and slowly move to a safe place on the side of the road.
The use of tire sealants is not recommended and may damage
your tires.
2004 U137 Excursion (hdw)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
174
