4. Fan speed: Press to manually
increase or decrease fan speed.
When in AUTO mode, will be
controlled automatically to meet the
desired temperature.
5.
(Floor/defrost): Distributes outside air through the windshield
defroster and floor vents.
6.
(Floor): Distributes outside air through the floor vents.
7.
(Panel/floor): Distributes outside air through the instrument
panel and floor vents.
8.
(Panel): Distributes outside air through the instrument panel
vents and the floor vents.
9. OFF: Press to turn the system
off.
10. Manual override controls:
Press any of these controls to leave
automatic mode and to manually
determine where airflow is directed. To return to full automatic control,
press AUTO.
11. AUTO: Press to engage
automatic mode. The system will
determine fan speed, airflow
location, and outside or recirculated air depending on the selected
temperature. Fan speed will remain automatic unless the fan control is
pressed to manually adjust.
12. EXT TEMP: Press to display
the outside temperature. Will remain
in the display until pressed again.
13. Temperature controls: Press
to manually increase or decrease the
desired temperature. In automatic
mode, the system will to heat or
cool the vehicle to the selected temperature.
Operating tips
• To reduce fog build up on the windshield during humid weather, place
the air flow selector in the
position.
2004 U137 Excursion (hdw)
Owners Guide (post-2002-fmt)
USA English (fus)
Climate Controls
45
