Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
25 10A Autolamp/Sunload sensor, Power
mirrors, Door lock switches,
Mirror switch, Keypad switch,
Decklid switch, Adjustable pedal
switch, DDM
26 10A Ignition (ON/START) - Cluster,
LCM, Overdrive cancel switch,
Rear defroster relay coil
27 20A Cigar lighter, OBD II
28 7.5A Center High-Mounted Stop Lamp
(CHMSL)
29 15A Audio
30 15A MFS, Stop lamps
31 15A Hazards (non-Police vehicles)
20A Hazards (Police vehicles)
32 10A Mirror heaters, Rear defroster
switch indicator
33 10A Ignition (ON/START), Fire
suppression module (if equipped)
(Police vehicles only)
Relay 1 Full ISO relay Rear defroster
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
Always disconnect the battery before servicing high current
fuses.
To reduce risk of electrical shock, always replace the cover to
the Power Distribution Box before reconnecting the battery or
refilling fluid reservoirs.
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and Specifications chapter.
2006 Crown Victoria (cro)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
190
