Ford 2009 Escape Hybrid User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
28 5A Radio
29 5A Instrument panel cluster
30 5A Not used (spare)
31 10A Restraints control module
32 10A Not used (spare)
33 10A Not used (spare)
34 5A Not used (spare)
35 10A Four wheel drive, EPAS
(steering), 110V inverter module,
Park aid module
36 5A PATS transceiver
37 10A Climate control
38 20A Subwoofer/Amp (Audiophile
radio)
39 20A Radio, Radio amplifier
(navigation)
40 20A Front power point
41 15A Driver/passenger door lock
switches, Auto dimming mirror,
Compass, Ambient lighting, Moon
roof
42 10A Not used (spare)
43 10A Rear wiper logic, Heated seats
relay, Instrument cluster
44 10A Not used (spare)
45 5A Front wiper logic, Blower motor
relay
46 7.5A OCS (restraints), PADI
(restraints)
47 30A Circuit
Breaker
Power windows
48 — Delayed accessory relay
2009 Escape Hybrid (ehv)
Owners Guide, 2nd Printing
USA (fus)
Roadside Emergencies
230
