Ford 2009 Escape Hybrid User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
5 10A* Powertrain Control Module (PCM)
Keep Alive power, PCM relay,
Transmission control module,
Canister vent
6 — Not used
7 15A* Liftgate latch
8 5A* Traction battery control module
9 50A** Brake control module
10 30A** Front wipers
11 — Not used
12 40A** Blower motor
13 10A* A/C clutch
14 10A* Heater/Coolant pump
15
50A** Traction Battery Control Module
(TBCM)
16 40A** Cooling fan 1
17 40A** Cooling fan 2
18 50A** Brake control module solenoid
19 30A** Power seats
20 — A/C clutch relay
21A — Rear defroster relay
21B — Ignition relay
21C — Blower relay
21D — PCM relay
22 15A* Ignition coils
23 15A* Fuel injectors
24 10A* Transmission control module
25 5A* Traction battery control module,
Thermal expansion valve
26 20A* Fuel pump, Traction battery
control module
2009 Escape Hybrid (ehv)
Owners Guide, 2nd Printing
USA (fus)
