Ford 2009 Focus - Passenger Compartment Fuse Panel

Passenger compartment fuse panel
The fuse panel is located below and to the left of the steering wheel by
the brake pedal. Remove the fuse panel cover to gain access to the fuses.
To remove a fuse use the fuse puller tool provided on the fuse panel
cover.
The fuses are coded as follows.
Fuse/Relay
Location
Fuse Amp
Rating
Protected circuits
1 30A Not used (spare)
2 15A Brake Switch CHMSL
3 15A Satellite radio
4 30A Not used (spare)
5 10A Shift Interlock
6 20A Right Front Turn lamp/Left Front
Turn lamp, Rear stop/turn lamps
2009 Focus (foc)
Owners Guide, 2nd Printing
USA (fus)
Roadside Emergencies
187
