Standard fuse amperage rating and color

COLOR

Fuse

rating

Mini

fuses

Standard

fuses

Maxi

fuses

Cartridge

maxi

fuses

Fuse link

cartridge

2A Grey Grey — — —

3A Violet Violet — — —

4A Pink Pink — — —

5A Tan Tan — — —

7.5A Brown Brown — — —

10A Red Red — — —

15A Blue Blue — — —

20A Yellow Yellow Yellow Blue Blue

25A Natural Natural — Natural Natural

30A Green Green Green Pink Pink

40A — — Orange Green Green

50A — — Red Red Red

60A — — Blue Yellow Yellow

70A — — Tan — Brown

80A — — Natural Black Black

Passenger compartment fuse panel

The fuse panel is located below and to the left of the steering wheel by

the brake pedal. Remove the panel cover to access the fuses.

To remove a fuse use the fuse puller tool provided on the fuse panel

cover.
