Ford 2011 Fusion Hybrid User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
32 30A* Driver power seat
33 20A* Moon roof
34 — Not used
35 40A* Front A/C blower motor (aux relay 3
power)
36 1A Diode Fuel pump
37 5A** Vacuum pump monitoring
38 10A** Heated side mirrors
39 10A** Transmission control module
40 10A** Powertrain control module
41 G8VA relay Backup lamps
42 G8VA relay Heater pump
43 G8VA relay Fuel pump
44 G8VA relay Motor electronics coolant pump
45 15A** Injectors
46 15A** Coil on plugs
47 10A** Powertrain control module (general):
Heater pump, Motor electronics
coolant pump relay coils, DC/DC
converter, Back-up lamps, Brake
controller
48 20A** HEV high voltage battery module,
Fuel pump relay
49
15A** Powertrain control module
(emissions related)
* Cartridge Fuses ** Mini Fuses
Roadside Emergencies
250
2011 Fusion Hybrid (hfv)
Owners Guide, 1st Printing
USA (fus)
