Do not exceed the maximum loads listed on the Safety Compliance
Certification label. For load specification terms found on the label, refer
to Vehicle loading–with and without a trailer in this chapter.
Remember to figure in the tongue load of your loaded vehicle when
figuring the total weight.
FWD
GCWR (Gross Combined Weight Rating)/Trailer Weight
Engine Maximum
GCWR-lb (kg)
Trailer weight
range-lb (kg)
(0-Maximum)
Tongue load-lb
(kg)
(0-Maximum)
3.5L Class I
towing
(standard)
7250 (3289) 0–2000 (0–907) 0–200 (0–91)
3.5L Class II
towing
(optional)
8420 (3819) 0–3500 (0–1588) 0–350 (0–159)
AWD
GCWR (Gross Combined Weight Rating)/Trailer Weight
Engine Maximum
GCWR-lb (kg)
Trailer weight
range-lb (kg)
(0-Maximum)
Tongue load-lb
(kg)
(0-Maximum)
3.5L Class I
towing
(standard)
7450 (3379) 0–2000 (0–907) 0–200 (0–91)
3.5L Class II
towing
(optional)
8620 (3910) 0–3500 (0–1588) 0–350 (0–159)
WARNING: Do not exceed the GVWR or the GAWR specified on
the certification label.
WARNING: Towing trailers beyond the maximum recommended
gross trailer weight exceeds the limit of the vehicle and could
result in engine damage, transmission damage, structural damage, loss
of vehicle control, vehicle rollover and personal injury.
Tires, Wheels and Loading
211
2009 Edge (edg)
Owners Guide, 3rd Printing
USA (fus)
