Figure 8
1. Area on top of instrument panel. Equipment must not interfere
with driver visibility.
2. Area on tunnel between seats
3. 9 inches (229 mm)
4. 12 inches (305 mm)
IMPORTANT AIR BAG DO’S AND DON’TS
Do not attempt to tamper with, disconnect or deactivate the air
bag system.
Tampering with an air bag system could cause the bag to inflate or
become inoperative. The air bag system should not be disconnected or
deactivated.
Do not mount or place any objects in the deployment path of an
air bag.
1
2
3
4
2008 Crown Victoria (cro)
Supplement
USA (fus)
Air Bag Information
26
