Truck Apps (if equipped)
In this mode, off-road and trailer towing application options are available.
*Off Road
Pitch and bank angle (in degrees): Displays the pitch angle (front to
rear) and bank angle (side to side) of the road surface.
Steering angle (in degrees): Displays the steering angle of the front
wheels after the vehicle has been driven for a period of time.
Differential lock/unlock: Displays the state (locked or unlocked) of the
electronic locking differential.
Torque flow: Displays the torque flow to the front and rear driveline
and operating mode of the transfer case: 4X2, 4X4 High, 4X4 Low,
AWD.
AdvanceTrac威 sport mode, hill descent control, off-road mode: Displays
which modes are active.
* If equipped—your vehicle may be equipped with some or all of these
options.
When “Press OK for info” is displayed, pressing OK will give you
information on the following options if equipped (Note: Information is
only available when traveling less than 3 mph [5 km/h]):
• 4X4 System
• AdvanceTrac威
• AWD (All-Wheel Drive)
• ELD (Electronic Locking Differential)
• HDC (Hill Descent Control)
• Off-Road Mode
Trailer: Press the right arrow key (when in the Off-Road menu) to
reach the Trailer menu. The following information is displayed
• Active trailer name or default trailer
• Accumulated trailer distance
• Trailer gain and output
• Trailer disconnected (Disregard this status if your vehicle is not
equipped with a factory installed trailer brake controller. This message
may appear when an aftermarket TBC is used even when the trailer is
connected.)
