Protected componentsFuse amp ratingFuse or relay number
Not used.—11
Not used.—12
Terminating resistor (120 ohm).Resistor13
Not used.—14
Not used.—15
Not used.—16
Not used.—17
Not used.—18
Brake on/off isolation relay.10A*19
Not used.—20
Not used.—21
Trailer tow electric brake controller.30A*22
Blower motor.40A*23
Not used.—24
Wipers.30A*25
Trailer tow park lamps.30A*26
Urea heaters (diesel engine).25A*27
Not used.—28
Trailer tow park lamps.Relay29
A/C clutch.Relay30
Wipers.Relay31
Not used.—32
Vehicle power 1.20A**33
Vehicle power 2.20A**34
Vehicle power 3.10A**35
Vehicle power 4.20A**36
Vehicle power 5 (diesel engine).10A**37
163
F650750 (TBC), enUSA, First Printing
Fuses
