REMOVING A HEADLAMP
E163822
1. Remove the four bolts from the
headlamp assembly.
2. Pull the assembly straight out
disengaging one snap clip from the
fender.
3. Disconnect the electrical connector by
squeezing the release tab and pushing
the connector forward, then pulling it
rearward.
CHANGING A BULB
WARNING
Bulbs can become hot. Let the bulb
cool down before removing it. Failure
to do so could result in personal
injury.
Headlamp bulbs must be marked with an
authorized D.O.T. marking for North
America to make sure they have the proper
lamp performance, light brightness, light
pattern and safe visibility.
Install in the reverse order unless otherwise
stated.
Headlamp Bulbs
1. Switch all of the lamps and the ignition
off.
2. Remove the headlamp. See
Removing a Headlamp (page 208).
3. Release the clip and remove the bulb.
Note: Do not touch the bulb glass.
Note: If the bulb is accidentally touched, it
should be cleaned with rubbing alcohol
before being used.
Front Clearance and Identification
Lamp (If Equipped)
E163825
1. Switch all of the lamps and the ignition
off.
2. Remove the screw and lens from the
lamp assembly.
3. Press the bulb in and turn the bulb
counterclockwise to remove it.
208
F650750 (TBC), enUSA, First Printing
Maintenance
