ASSEMBLY
Description Qty
Wheel
Axle
2
Supporting Leg
2
Hair pin
2
Hub Cap
Screw, Self-Tapping
2
2
Unpacking
1. Place box on a level surface.
2. Remove all items from box except the generator. Make sure all items listed on the packing list are included and not
damaged.
Packing List
Check all loose parts to the following list. Contact your dealer if any loose parts are not included.
Description Qty
Generator
1
Quick Start Guide
1
4-Cycle engine oil (SAE10W-30)
Toolkit
Spark Plug Wrench
Phillips screwdriver
10mm Combination Wrench
1
1
1
2
1
Washer
2
M8 x 16mm Hex Bolts for Foot
2
Funnel
1
+ +
++ + +
+ +
( )
10W30
OIL
+
Handles
2
Bushings (Flanged)
4
M8 x 45mm Hex Bolts for Handle
M8 Flanged Nuts for Handle
2
2
M8 Flanged Nuts for Foot
2
8 - 10
10 - 13
To Next Page
