Wheel Lug Nut Torque
Specifications
WARNING
When a wheel is installed, always
remove any corrosion, dirt or foreign
materials present on the mounting
surfaces of the wheel or the surface of the
wheel hub, brake drum or brake disc that
contacts the wheel. Make sure that any
fasteners that attach the rotor to the hub
are secured so they do not interfere with
the mounting surfaces of the wheel.
Installing wheels without correct
metal-to-metal contact at the wheel
mounting surfaces can cause the wheel
nuts to loosen and the wheel to come off
while the vehicle is in motion, resulting in
loss of control.
Retighten the lug nuts to the specified
torque at 500 miles (800 kilometers) after
any wheel disturbance (such as tire
rotation, changing a flat tire, wheel
removal).
lb-ft (Nm)*Bolt size
100 (135)M12 x 1.5
Torque specifications are for nut and bolt
threads free of dirt and rust. Use only Ford
recommended replacement fasteners.
TECHNICAL SPECIFICATIONS
Wheel specifications
17 in. x 7.0 in.Diameter and width
47.5 mmOffset
5.8 in. (149.5 mm)Backspacing
63.3 mmCenter bore
22.5 lb. (10.2 kg)Weight
23
Fiesta (CCT)
Wheels and Tires
