Cycler Set-Up Tips
How do I load the cassette?
Make sure that the Liberty cycler is positioned near the front of the table or cart so that all lines
can hang freely from the cassette.
Open the cassette door by pressing the latch on top of the door.
With the plastic domes facing outward, insert the top portion of the cassette then snap the
lower portion into place.
Close the cassette door securely.
NOTE: The cassette cannot be inserted unless your cycler is prompting “insert cassette”.
If you attempt to insert it at any other time, the cassette will not snap into place and the door
will not close.
CAUTION: The integrity of the cassette and film can be compromised if mishandled or misused.
Improper loading of the Liberty cassette into the Liberty cycler could cause damage to the flexible film.
Ensure the cassette is seated under both upper guide pins, is flush with the back plate, and is held by
the lower catch, before closing the cassette door.
