1. Metal shell
2. Drawer
3. Observation window: See how much ice has been stored in the drawer.
4. Handle for drawer.
5. Control Panel:
Indicator light: Lack of water in reservoir, Power, Ice full
Button: ICE, CLEAN, LIGHT
6. Water reservoir
7. Handle for water reservoir
8. Hot Air outlet
9. Drip tray
Water drain cap: After cleaning procedure, remove drain cap from the back of
the appliance, pull out the cap from the drainpipe, empty the tank under the
drawer, then reinsert the cap and put it back again.
Drainpipe: After cleaning procedure, you can collect dirty water from the
drainpipe (there are two pipes: one connects to the evaporator, the other one
connects to the water tank under the drawer).
Power cord
10.
11.
12.
GETTING TO KNOW YOUR UNIT
