Frigidaire FFCD2413UW User Manual

8
OPERATING INSTRUCTIONS
Operating Instructions
Getting Started
1. Load Dishwasher (See Dish
Preparation).
2. Add detergent (See Filing the
Detergent Dispenser).
3. Add Rinse Aid, if needed (See Rinse
Aid).
4. Select desired Cycle (See Cycle and
Option Chart). The cycle indicator
light will glow when selected.
5. Select desired Option (See Cycle
and Option Chart). The indicator
light beside the option will glow
when selected.

NOTE
If the dishwasher door is opened while
the unit is running, the START/CANCEL
pad must be pressed and the door shut
immediately to return the unit to the
selected cycle and option, this must
happen within 10 minutes for the unit to
continue the cycle.
Cycle and Option Chart
* Select the Normal and High Temp options along with a Rinse Aid agent for improved
drying performance.
Cycle and intended use Selectable Options
Temperature; Drying
Water per Cycle
(approx.)
Duration* (ap-
prox.)
Heavy Wash
Recommended for pots,
pans, casseroles and
dinnerware having light
to heavily soiled loads.
High Temp, Heat Dry 6.7 gal.
25 L.
2 - 3 Hours
Normal Wash*
Recommended for light-
ly to heavily soiled loads.
High Temp*,Normal
Heat Dry
3 - 6.7 gal.
11 - 25 L.
1
1
/
2
- 3 Hours
1 Hr. Wash
Recommended for light-
ly soiled loads only.
Normal, Heat Dry 5.4 gal.
20 L.
1 Hour
*Does not include drying time.
6. Run hot water faucet nearest
dishwasher until water is hot. Turn
water o.
7. To start, press START/CANCEL pad.
8. Immediately close door to latch.

Frigidaire FFCD2413UW Specifications

General

Style	built in
Color	white
Load Capacity	14 place settings
Number of Cycles	3
Drying Type	static vent; heated & vented
Noise level	60 db
Control Type	touchpad
Delay Start	yes; 4 hours
Child Lock	yes
Spray Arms	3
Water Filter	poly; no
Water Softener	no
Food Disposer	yes; hard
Wi-Fi	no
Voltage	120 volts
Current	15

Weight and Dimensions

Depth	25 inch
Height	33 1/2 inch
Width	24 inch
