Frigidaire FFTR1835VW User Manual

13
DOOR HANDLE INSTALLATION (SOME MODELS)
To attach the metal refrigerator handle
(Stainless steel, Black Stainless steel,
Stainless Steel EZCare):
1. Place the rounded part of the handle
onto the shoulder screw on the face
of the door and align the 2 holes in
top of handle with the 2 holes in top
of the door. Do not tighten the set
screw yet.
2. Install the 2 screws into the top of
the handle.
3. Tighten the set screw on the rounded
part of the handle until the handle
is flush with the door; then tighten
another ½ turn.
Screw
Handle
Button
Plug
Set
Screw
Shoulder
Screw
Shoulder
Screw
Nameplate
Handle
Set Screw
Screw
Rounded Doors
To attach the metal freezer handle
(Stainless steel, Black Stainless steel,
Stainless Steel EZCare):
1. Place the rounded part of the handle
onto the shoulder screw on the face
of the door and align the 2 holes in
bottom of handle with the 2 holes in
bottom of door. Do not tighten the
set screw yet.
2. Install the 2 screws into the bottom
of the handle.
3. Tighten the set screw on the
rounded part of the handle until the
handle is flush with the door; then
tighten another ½ turn.
Flat Doors

Frigidaire FFTR1835VW Specifications

General

Type	freestanding
Style	top freezer
Color	white
Number of Doors	2
Total Capacity	18.3 cubic feet
Refrigerator Capacity	13.4 cubic feet
Freezer Capacity	4.9 cubic feet
Humidity Controlled Crispers	yes
Minimum Refrigerator Temperature	45 degrees fahrenheit
Maximum Refrigerator Temperature	110 degrees fahrenheit
Defrost System	automatic
Number of Refrigerator Shelves	3
Temperature Control	electromechanical
Interior Light	led
Dispenser	none
Ice Maker	optional
Water Filter	no
Smart Home	no
Annual Energy Consumption	410 kilowatt hours
Voltage	120 volts
Current	3 amperes

Weight and Dimensions

Depth	30.375 inches
Height	66.375 inches
Width	30 inches
Net Weight	155.8 pounds
