23
To remove upper freezer drawer:
1 Open freezer compartment completely.
2 Lift up and out to remove upper freezer
drawer.
Reverse the steps to reinstall drawer.
Freezer Drawer
Freezer Features (varies by model)
STORAGE FEATURES
NOTE
If basket is not resting on stabilizer bar
retainer clips, the drawer will not close
properly.
Plastic Lower Basket Divider
Lower Basket
Divider
To remove freezer basket:
1 Open freezer compartment completely.
2 Lift the basket up and remove.
Reverse the steps to reinstall freezer basket.
Dividers
Grab hand hold on lower divider and pull up
slightly to slide to next position. (The divider
cannot be removed.)
IMPORTANT
There are wheels on the bottom of the
drawer. Make sure all wheels are aligned on
their respective tracks for proper function. If
drawer is not aligned properly, it will cause
problems with the door operation.
Adjustable Door Bins
To move door bin side-to-side:
1 Tilt bin up so the back of the bin is off the
door but the hook is still engaged.
2 Slide bin along rail to desired position.
3 Lower bin back into place.
To move door bin up or down:
1 Lift bin up disengaging the hook.
2 Move bin to desired rail location.
3 Push bin hook into rail engaging the hook.
