Frigidaire FGIC3666TB User Manual

5
COOKTOP FEATURES
Read these instructions carefully before
using the cooktop
1. Left Rear Single Radiant Element
2. Bridge Radiant Element
3. Left Front Radiant Element
4. Right Front Induction Element
5. Right Rear Induction Element
6. Center Rear Single Radiant Element (Fig. 2 only)
7. Right Rear Element Control Knob
8. Left Rear Element Control Knob
9. Left Front Element Control Knob
10. Right Front Element Control Knob
11. Center Rear Element Control Knob (Fig. 2 only)
12. Rear Pilot Light (Element On)
13. Front Pilot Light (Element On)
INDUCTION ELEMENT CHARACTERISTICS
(RIGHT FRONT AND REAR ELEMENTS)
A COOLER COOKTOP- A unique feature of the Induc-
tion Cooktop is whether turned ON or OFF, the cooktop
surface remains cooler than standard ceramic cooktops.
MAGNETIC DETECTOR- The coil sensor automatically
detects whether the pan is magnetic and eliminates ac-
cidental “turn-On.”
PAN SIZE DETECTION- The pan recognition sensor
automatically detects and adapts the Cooking Zones to
the pan sizes in use.
EFFICIENT- Induction cooking heats faster while using
less energy. Induction power levels are quick to boil and
when simmering.
CAUTION
The Cooking Zones may appear to be cool while turned
ON and after they have been turned OFF. The glass
surface may be HOT from residual heat transferred
from the cookware and burns may occur.
Figure 1 - 30“ Model
Figure 2 - 36“ Model
1
2
3
5
4
7
8
9
10
12
13
1
2
3
65
4
11
8
9
10
7
12
13

Frigidaire FGIC3666TB Specifications

General

Style	smoothtop
Color	black
Griddle	no
Induction	yes
Number of Cooking Zones	5
Downdraft Vent	no
Cooktop Element	5
Control Type	digital
Power Consumption	3800 watts
Voltage	240 volts
Current	45.2 amperes

Weight and Dimensions

Depth	21 1/2 inches
Height	4 2/5 inches
Width	36 5/7 inches
Cutout Depth	20 1/2 inches
Cutout Height	5 inches
Cutout Width	36 3/4 inches
Net Weight	48 pounds
