Frigidaire Refrigerator Use & Care Guide

13
INSTALLING DOOR HANDLES
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.

NOTE
All set screws should be tightened so the screw is below the surface of the handle. The handles
should be drawn tight to freezer and refrigerator doors with no gaps. Opening the opposite door
while tightening the Allen screw makes installation easier.
The door handle may loosen over time or if it was installed improperly. If this happens, tighten the
set screws on the handles.
Door Handle Mounting
Instructions for Frigidaire
1 Remove handles from carton and
any other protective packaging.
2 Position fresh food handle end caps
over upper and lower pre-installed
shoulder bolts (A) that are fastened
into door, ensuring the holes for the
set screws are facing towards the
opposite door.
 3 Whileholdinghandlermlyagainst
door, fasten upper and lower Allen set
screws (B) with supplied Allen wrench.
4 Repeat steps 2 and 3 to install
opposite handle. Ensure the holes
for the set screws are facing
towardstherstdoor.
5 Position freezer handle end caps
over left and right pre-installed
shoulder bolts that are fastened to
the door, ensuring the holes for the
set screws are facing down.
 6 Whileholdinghandlermlyagainst
door, loosely tighten right Allen
set screw (B) with supplied Allen
wrench until there is no gap
between handle and door.
 7 Stillholdingthehandlermlytothe
door,rmlytightenleftAllenset
screw (B) with supplied Allen wrench.
8 Return to the right Allen set screw
(B)andrmlytightenwithsupplied
Allen wrench.
Mounting Freezer Handle
Mounting Refrigerator Handles
