Hardware Overview

Front Panel Ports

Ports Description

RJ45

SFP

10/100/1000Base-T RJ45 port for Ethernet connection

Hot swappable SFP port for 1G ber connection

LED Status Description

TP/LNK

Green

Link through copper port is successfully

established.

Copper port is actively sending or

receiving data.

Copper port is linked down.O

Blinking

Green

Front Panel LEDs

GIGAMC

1000M PWRFX/LNK

TP/LNK

TP/LNK 1000M FX/LNK PWR

RJ45 Port

GIGAMC

1000M PWRFX/LNK

TP/LNK

SFP Port
