S3900 SERIES SWITCHES RESET AND RECOVERY SYSTEM CONFIGURATION GUIDE
www.fs.com
1. Function Introduction
Resetting a device usually means restoring the device's configuration to the factory configuration. In some cases, we will need to use the
device reset function, such as a one-click recovery after the switch test is completed.
2. Configuration Considerations
Table 1 shows examples of applicable products and versions.
3. Command Line Reset
3.1 Network Topo
3.2 Configuration Steps
3.2.1 Connection Equipment
#Connect the PC and the switch to the network cable and the console port. Connect one end of the RJ-45 network cable to the network
card interface of the PC and the other end to the network port of the SW. Connect one end of the console cable USB to the USB port of
the PC. One end of the RJ-45 is connected to the console port on the front panel of the switch.
3.2.2 Download Configuration Software
#After the connection is completed,there we recommend the super terminal, putty or Secure CRT tool to configure the switch.
3.2.3 Switch on and Use Login Software
#Energizing the switch, then open the installed login software, select the serial port of login mode, port through the device manager
to determine. Baud rate :115200,Data bits: 8, Parity: None ,Stop bits: 1.(Reference below)
